Rock Preparation Lab (ERB-1114)

Initial rock sample preparation is housed in a single comprehensive laboratory serviced by a Nederman Modular Filtration System with HEPA filtration and four articulating point-source fume arms. The equipment in this laboratory includes:

  1. a full rock cutting and polishing suite including a variety of diamond saws, a thin section cut-off saw, grinding wheels, vibramat slab polisher, and impregnation equipment for thin section and mineral mount preparation;
  2. a full rock crushing and first-stage mineral separation suite including a Bico jaw crusher, a Bico rotary disc mill, shaker sieves, and pyramid-style water table for water-based density separation;
  3. a full rock powdering suite including a Spex ball mill and Shatterbox with alumina grinding vessels for geochemical powder preparation.
Rock preparation lab featuring Nederman MFS HEPA-filtration
Rock preparation lab featuring Nederman MFS HEPA-filtration
Thin-section laboratory including cut-off saw and thinner, polishing wheels, and vibramat slab polisher
Thin-section laboratory including cut-off saw and thinner, polishing wheels, and vibramat slab polisher
Bico disk mill and jaw crusher.
Bico disk mill and jaw crusher
large-format pyramid-style water separation shaking table.
Large-format Pyramid-style water separation shaking table
large format slab saw
Large-format slab saw
spex shatterbox with alumina ceramic and tungsten carbide mills.
Spex shatterbox with alumina ceramic & tungsten carbide mills.
New water-cooled high-speed trim saw.
New water-cooled high-speed trim saw
Miniature jaw crusher and disk mills with alumina ceramic and tungsten carbide face plates for small scale sample preparation.
Miniature jaw crusher and disk mills with alumina ceramic and tungsten carbide face plates for small scale sample preparation
Spex dual mixer mill with agate, alumina ceramic, tungsten carbide, steel, and plastic ball mills.
SPEX dual mixer mill with agate, alumina ceramic, tungsten carbide, steel, and plastic ball mills for a variety of sample matrices.
Mini lathe and vertical mills
Miniature lathe and vertical mills for in-house fine machining
nederman_340

Rock preparation lab featuring Nederman MFS HEPA-filtration.

dmjc2_340

Bico “Chipmunk” jaw crusher and direct-drive disk mill.

slabsaw_340

Diamond slab saw.

thinsection_340

Thin-section laboratory including cut-off saw and thinner, polishing wheels, vibramat slab polisher, and vertical milling machine.
watertableboth_340Pyramid-type water table for density separation of mineral sands.
shatterbox_340Spex shatterbox.
